The N133HCE-EN1 (product code: CMN1372) launched by Innolux is a 13.3-inch LCD module product that adopts a-Si TFT-LCD technology. It is equipped with WLED backlight, including LED driver for backlight driving, and does not support touch functionality.

White LED backlight, includes LED driver, reverse-mounted terminals, matte surface, eDP1.2. Its operating temperature is 0–50°C, storage temperature is –20–60°C, and vibration resistance is 1.5G (14.7 m/s²). This model is suitable for notebook applications.



The N133HCE-EN1 features a display resolution of 1920(RGB)×1080 (FHD) with an aspect ratio of 16:9 (width:height) and employs an RGB vertical stripe pixel arrangement. Its active display area measures 293.76×165.24 mm (width×height), while the overall physical dimensions are 305.35×193.46×2.6 mm (width×height×thickness). The surface treatment is matte with Hard Coating (3H), and the product’s net weight is 217/230 g (Typ./Max.). The appearance style is slim panel (with PCBA flat, thickness ≤3.2 mm).For backlighting, this product utilizes a WLED side-lit light source with a lifespan of 15K hours and includes an LED driver. The N133HCE-EN1 is equipped with an eDP (2 Lanes) signal interface, totaling 30 pins, connected via terminals, and requires a driving voltage of 3.3V (Typ.). Its typical vertical refresh rate (Fv) is 60Hz.
