B173HAN01.3 (Product Code: AUO139D) is a 17.3-inch LCD module product utilizing a-Si TFT-LCD technology, developed by AUO (AUO Display Technology Corporation). It features a WLED backlight with integrated LED driver backlight control and is non-touch.

The B173HAN01.3 features a display resolution of 1920 (RGB) × 1080 (FHD) with a 16:9 (width:height) aspect ratio, employing RGB vertical stripe pixel arrangement. Its active display area measures 381.888 × 214.812 (width × height) mm, while the external dimensions are 398.1 × 250.5 (width × height) × 4 (thickness) mm. The surface finish is matte with a hard coating (3H), and the product’s net weight is 550g (max). The appearance style is medium-thick (PCBA flat, thickness 3.4~4.0mm). For backlighting, this product utilizes a side-lit WLED light source with a lifespan of 15K hours, including an LED driver. The B173HAN01.3 adopts an eDP (2 lanes) signal interface with a total of 30 pins, connected via terminals, and operates at a typical driving voltage of 3.3V. Its standard vertical refresh rate (Fv) is 60Hz.
