MV270QUM-N60 (Alternative Name: MV270QUM-N60-AD30) is a 27.0-inch LCD module launched by BOE Technology Group Co., Ltd. (BOE), utilizing a-Si TFT-LCD technology. It is equipped with WLED backlight, has no backlight driver, and does not support touch functionality. According to the product specification document version AD30_Ver.O released by BOE on October 8, 2021, the MV270QUM-N60 features a display resolution of 3840(RGB)×2160 (UHD), an aspect ratio of 16:9 (width:height), and employs an RGB vertical stripe pixel arrangement. Its active area dimensions are 596.736×335.664 mm (width×height), while its outline dimensions are 608.8×353.3 mm (width×height)×13.9 mm (thickness). The surface treatment includes an anti-glare matte finish (Haze 25%) and hard coating (3H). The product’s net weight is 3.26 kg (Typical). For backlighting, this module uses a 23S4P WLED edge-lit light source (bottom), with a light source lifetime of 30K hours, and does not include a backlight driver. The MV270QUM-N60 utilizes an eDP (4 Lanes) signal interface with a total of 30 pins, employs a connector connection, and requires a driving voltage of 10.0V (Typical). Its typical vertical refresh rate (Fv) is 60Hz.
