BOE’s PV173FHM-N80 (Product Code: BOE084E) is a 17.3-inch LCD module utilizing a-Si TFT-LCD technology. It incorporates a WLED backlight with an LED driver for backlight driving and does not support touch functionality.

According to panel specifications, its key features include: white LED backlight with an integrated LED driver, inverted terminal connections, a matte surface, and eDP 1.2 interface. The operating temperature ranges from 0 to 50°C,

storage temperature from -20 to 60°C, and vibration resistance up to 1.5G (14.7 m/s²). This model is suitable for notebook applications.

The PV173FHM-N80 display has a resolution of 1920 (RGB) × 1080 (FHD), with an aspect ratio of 16:9 (width:height), and employs a vertically striped RGB pixel arrangement. Its active area measures 381.888 × 214.812 mm (width × height), while the overall dimensions are 389.888 (width) × 238.012 (height) × 3.5 (thickness) mm. The surface features a matte finish with hard coating (3H hardness),

and the product has a net weight of 480g (max.) with a medium-thick design (PCBA flat, thickness ranging from 3.4 to 4.0mm).For backlighting, this product utilizes a 10S5P WLED edge-lit light source, which has a lifespan of 15,000 hours and includes an LED driver. The PV173FHM-N80 adopts an eDP (2 lanes) signal interface with a total of 30 pins, connected via terminals, and operates at a drive voltage of 3.3V (typical). Its typical vertical refresh rate (Fv) is 60Hz.
