NT173WDM-N27 (Product Code: BOE09EC) is a 17.3-inch a-Si TFT-LCD display module launched by BOE. It is equipped with a WLED backlight, including an LED driver for backlight driving,

and does not support touch functionality. The operating temperature range for this product is 0 to 50°C, with a storage temperature range of -20 to 60°C,
and a vibration resistance of 1.5G (14.7 m/s²). Its typical features, as summarized by the panel database, include: white LED backlight with an LED driver, flip mounting of terminals, matte surface, and eDP1.2 interface.

The NT173WDM-N27 features a display resolution of 1600(RGB)×900 (HD+), with an aspect ratio of 16:9 (width:height) and RGB vertical stripe pixel arrangement. Its active area measures 382.08(width)×214.92(height) mm, while the overall dimensions are 398.1(width)×249.1(height)×4(thickness) mm.

The surface treatment is matte with Hard Coating (3H), and the net weight is 540g (Max.), designed with a medium-thick profile (flat PCBA, thickness 3.4–4.0mm).This product utilizes a side-edge WLED backlight system with 11S5P configuration,

offering a lifespan of 15K hours and including an LED driver. It adopts an eDP (1 Lane) signal interface with 30-pin terminal connections and a driving voltage of 3.3V (Typ.). The typical vertical refresh rate (Fv) is 60Hz.
