The ATNA60YV03-0 launched by Samsung is a 16.0-inch screen assembly product using AM-OLED technology, which emits light on its own. The typical feature of the screen is 10 bit grayscale, for Dell Precision 7670. Its working temperature is -20~70 ° C and storage temperature is -40~85 ° C. This model is suitable for use in laptops.. The display resolution of ATNA60YV03-0 is 3840 (RGB) × 2400 (WQUXGA), with an aspect ratio of 16:10 (width: height). The pixels are arranged in RGB vertical stripes, and the pixel density calculated by the screen library is 283 PPI. Its display area size is 344.448 × 215.28 (width × height) mm. This product is self luminous. ATNA60YV03-0 adopts eDP (4 Lanes) signal interface and terminal connection
ATNA60YV03-0 3840×2400 QHD IPS LED 液晶显示器屏幕总成
ATNA60YV03-0
面板品牌:三星 (Samsung)
面板型号:ATNA60YV03-0
面板尺寸:16.0英寸
面板类型:AM-OLED, 屏幕总成
分辨率:3840(RGB)×2400, WQUXGA, 283PPI
像素布局：RGB垂直条状
显示区域：344.448(W)×215.28(H) mm
对比度：100000:1 (Typ.) (TM)
可视角度：88/88/88/88 (Typ.)(CR≥10) 左 / 右 / 上 / 下
视角方向：全视角
反应时间：1 (Typ.)(Tr+Td)
显示颜色：1.07B
光源类型：自发光
面板应用：笔记本
信号接口：eDP (4 Lanes) , 端子
工作环境：工作: -20 ~ 70 °C ; 存储: -40 ~ 85 °C
